Elation COL110 Color Pendant Wash Luminaire 110W RGBW LED Pendant Light
- Brands Elation
- Product Code:ELAT-COL110
- Availability:In Stock
-
$1,060.00
The new COLOUR PENDANT wash luminaire features (36) 3W RGBW LEDs producing a 41° beam angle, fully blended color transformations, convection cooled, silent operation, and adjustable frequency settings for flicker free operation for TV and Film. It includes selectable dimming curves, strobe and color macro effects, RDM (Remote Device Management), 5pin DMX in/out and powerCON input connections, an internal E-FLY extended range wireless DMX transceiver, an LCD menu display with 4 button control panel, removable pendant and yoke mounting brackets, a multi-voltage universal auto switching power supply (100-250v), and exterior shroud kits available.
Features:
- 41° Beam Angle - 66° Field Angle
- Fully Blended Color Transformations
- Adjustable Frequency Settings for Flicker FREE Operation for TV and FILM
- Convection Cooled / Silent Operation
- Removable Pendant and Yoke Mounting Brackets
- E-Fly Internal Extended Range Wireless DMX Transceiver
Specifications:
- SOURCE
- (36) 3W RGBW LEDs
- 100,000 Hour Average Life*
*LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA - 3,650 LUX 339 FC @3.3' (1m) (41°Full ON)
- 1,020 LUX 95 FC @6.6' (2m) (41°Full ON)
- 458 LUX 43 FC @9.8' (3m) (41°Full ON)
- 255 LUX 24 FC @13.1' (4m) (41°Full ON)
- 164 LUX 15 FC @16.4' (5m) (41°Full ON)
EFFECTS - Strobe and Color Macros
- Dimming : 0% - 100%
- Selectable Dimming Curves
CONTROL / CONNECTIONS - 11 DMX Channel Modes (1 / 3 / 4x2 / 5x2 / 6x2 / 7 / 8 / 10)
- Frequencies (1200Hz, 2400Hz, 4800Hz, 9600Hz)
- E-FlyT Internal Extended Range Wireless DMX Transceiver
- 4 Button Control Panel and LCD Menu Display
- 5pin DMX In/Out
- RDM (Remote Device Management)
- powerCON Power In
SIZE / WEIGHT - Length: 14.7" (374 mm)
- Width: 9.9" (252.5 mm)
- Horizontal Height: 12.0" (308.8 mm)
- Weight: 14.0 lbs. (6.4 kg)
ELECTRICAL / THERMAL - AC 100-240V - 50/60Hz
- 110W Max Power Consumption
- -14°F to 113°F (-10°C to 45°C)
APPROVALS / RATINGS - CE | cETLus | IP20
Item Includes:
- (1) powerCON Cable
Warranty:
- 2 Years
